Midland Alloys Inc. is a trusted Indian manufacturer and global supplier of Inconel 600 alloy forged fittings, offering high-performance components engineered for extreme environments. Designed for durability and long-term use, these fittings are ideal for industries that demand strength and resistance under pressure. Inconel 600 is a nickel-chromium-iron alloy known for its excellent corrosion and heat resistance. These forged fittings are stable in high-temperature and corrosive applications as they adhere to stringent industrial standards and have a consistent chemical composition, with at least 72% nickel, 14–17% chromium, and up to 10% iron. They exhibit strong mechanical properties with a minimum tensile strength of 655 MPa, yield strength of 310 MPa, and elongation up to 30%. The material maintains excellent formability and toughness, even in cryogenic conditions. The reduction of area is typically 42%, confirming its strong structural integrity under stress.
Benefits of Inconel 600 Forged Fittings
UNS N06600 forged fittings offer superior reliability, strength, and resistance in demanding industrial applications. Their performance remains consistent across fluctuating environments and aggressive media.
- Outstanding corrosion resistance in alkaline and acidic conditions
- Outstanding resistance to oxidation at high temperatures
- Strong structural integrity in the face of heat and mechanical strain
- Maintains its mechanical strength in both hot and cold conditions
- Provides chemical processing systems with long-term durability
- Exceptional hardness makes it appropriate for high-pressure systems
- Prevents corrosion, pitting, and cracking from chloride ion stress
The primary differences between Inconel 600 and Inconel 718 forged fittings are composition, strength, and temperature performance. The UNS N06600 solid solution nickel chromium iron alloy has a comparatively high temperature tolerance, and remarkable corrosion resistance. It is appropriate for thermal processing, chemical plants and food grade steam applications as it functions well at temperatures as high as 1093°C. On the other hand, Inconel 718 is a precipitation-hardened nickel-chromium alloy with added molybdenum, niobium, and titanium, offering much higher tensile and creep strength. It is frequently utilized in high-stress turbine components and aerospace as it maintains its mechanical properties at temperatures as high as 704°C. While 600 is ideal for corrosion and heat resistance, 718 is chosen for strength in pressure-intensive systems.
Specification of Inconel 600 Forged Fittings
Socketweld : 1/8" to 4" NB
Screwed-Threaded : 1/8" to 4" NB
ASTM B564/ASME SB564
ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Forge, Cast, Push, Press, etc.
2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Socketweld Fittings, Screwed-Threaded Fittings
Types of Inconel 600 Forged Fittings
Manufacturing Types
-
Threaded Forged FittingsDesigned with internal or external threads, these fittings allow quick assembly and disassembly without welding.
-
Socket Weld Forged FittingsThese fittings are joined by inserting the pipe into a recessed area of the fitting and welding around it, ensuring strong, leak-proof joints.
-
Screwed FittingsSimilar to threaded types, screwed fittings are connected using screw threads, making installation simple and cost-effective.
-
BSPTBushings help reduce the bore size in a fitting or valve connection by joining pipes of varying diameters.
-
NPTEnd caps are used to seal a pipeline's end, shielding it from impurities and guaranteeing closed systems' safety.
Forms
-
Forged ElbowElbows, which come in 45° and 90° varieties shift the direction of flow with little pressure loss.
-
Forged BushingBushings help reduce the bore size in a fitting or valve connection by joining pipes of varying diameters.
-
Forged TeeUsed to split or combine flow across three directions essential for branching pipeline.
-
Forged CouplingOffer a safe connection between two pipes; threaded and socket-welded options are available.
-
Forged PlugClose open pipe ends which are frequently used for isolation or testing.
-
Forged CrossWith four openings, cross fittings help connect four pipes used when fluid distribution needs to occur in multiple directions.
Contact us today to discuss how Inconel 600 Forged Fittings can benefit your application. Whether you need guidance in selecting the right pipes or have specific requirements, our team of experts is here to help you find the optimal solution.
Technical Details & Delivery Condition
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015 max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.47 g/cm3 | 1413 °C (2580 °F) | 655 MPa, 95000 psi | 310 MPa, 45000 psi | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
Inconel Forged Fittings Grades We Offer
Inconel 600 Forged Fittings Price List
| Price List of Inconel 600 Forged Fittings</strong > | Inconel Alloy 600 Forged Fittings Price in India (INR)</strong > | Alloy 600 Forged Pipe Fittings Price in USD</strong > | Inconel 600 Forged Fittings Price in UAE (Dirham)</strong > |
| 600 Inconel Forged Elbow Price List | ₹ 620 | $ 7.69 USD | 25.58 AED |
| Inconel® Alloy 600 Forged Fittings Cost | ₹ 1200 | $ 14.82 USD | 48.11 AED |
| Inconel 600 Socketweld Pipe Elbow Price | ₹ 5800 | $ 70.17 USD | 270.30 AED |
| Inconel® 600 Forged Fittings Prices | ₹ 1607 | $ 25.78 USD | 82.30 AED |
| Inconel 600 Street Elbow Price | ₹ 585 | $ 6.85 USD | 25.50 AED |
| Inconel 600 Forged Equal Tee Price | ₹ 1173 | $ 15.06 USD | 30.96 AED |
| Price of Pressure Class 2000LBS Inconel 600 Forged Fittings | ₹ 841 | $ 12.33 USD | 42.61 AED |
| Price of Inconel 600 Couplings | ₹ 1297 | $ 18.00 USD | 65.44 AED |
| Inconel Alloy 600 Threaded Fittings Price List | ₹ 2300 | $ 26.21 USD | 120.27 AED |
Inconel 600 Forged Fittings Manufacturing Standards
| Standard | Types | Class Rating/Schedule | Ends | Size |
| ASME B16.11 | 90°Elbow/ 45°Elbow/ Tee/ Cross | 2000LB | Threaded | 1/4”~4” |
| 90°Elbow/ 45°Elbow/ Tee/ Cross/Pipe Cap/ Half Coupling/Full Coupling | 3000LB/6000LB | Threaded | 1/4”~4” | |
| Socket-welding | 1/8”~4” | |||
| 90°Elbow/ 45°Elbow/ Tee/ Cross/Half Coupling/Full Coupling | 9000LB | Socket-welding | 1/2”~2” | |
| Street Elbow | 3000LB | Threaded | 1/8”~2” | |
| 6000LB | 1/8”~1-1/2” | |||
| Lateral Tee | 3000LB | Socket-welding | 1/4”~2” | |
| 6000LB | 1/2”~1-1/2” | |||
| 3000LB | Threaded | 3/8”~2‘’ | ||
| 6000LB | 1/2”~2” | |||
| 9000LB | 1/2”~1-1/2” | |||
| Flush Bushing/Hex Bushing/Hex Plug/Round Plug/Square Plug | 3000LB/6000LB | Threaded | 1/8”~4” | |
| MSS SP79 | Reducer Inserts | 3000LB/6000LB/9000LB | Socket-welding | 3/8‘’x1/4”~2×1/2” |
| MSS SP83 | Union | 3000LB | Socket-welding/Threaded | 1/8”~3” |
| MSS SP95 | Concentric/Eccentric Swaged Nipples | See Below Note1 | 1/4‘’~12” | |
| Bull Plugs | Threaded | 1/8”~12” | ||
| MSS SP97 | Weldolet | – | – | – |
| Sockolet | 3000LB/6000LB | Socket-welding | 1/8”~6” | |
| Threadolet | 3000LB/6000LB | Threaded | 1/8”~6” | |
| Nipolet | XS/XXS | Plain/Threaded | 1/2”~2” | |
| Elbolet | 3000LB/6000LB | Socket-welding/Threaded | 1/4”~2” | |
| – | – | – | ||
| Latrolet | 3000LB/6000LB | Socket-welding/Threaded | 1/2”~2” | |
| – | – | – | ||
| Flangolet,Nipolet,Sweepolet,etc. available as per client’ demands. | ||||
| BS3799 | Hex Nipple | 3000LB/6000LB | Threaded | 1/8”~2”x1/2” |
| Bosses | 3000LB | Threaded | 1/8”~2” | |
| 6000LB | Threaded | 1/8”~4” | ||
Manufacturing Standards of Inconel 600 Forged Fittings
Raw Material
Cutting
Sizing
Heat Treatment
Pickling
Beveling
Polishing
Sand Blasting
Pickling / Passivating
Inspection
Analytic
Marking
Packing & Shipping
Applications of Inconel 600 Forged Fittings
Inconel 600 forged pipe fittings are widely used in industries that demand resistance to corrosive media, high heat, and mechanical stress. As these flanges deal with oxidizing acids, caustic alkalis, and chlorinated solvents, they are crucial in chemical processing facilities. It offers safe connections in high-temperature cracking and reforming units in petrochemical refineries. Due to their metallurgical stability, ASTM B564 Inconel 600 forged fittings are used in nuclear power plants’ steam generators, and heat exchangers. Inconel 600 socket weld forged fittings are utilized in the food processing industry in steam sterilizers, as they can resist organic acids. Forged fittings are also part of marine engineering, aerospace equipment, and thermal oxidizers, where UNS N06600 forged fittings provide unequal reliability.
Why Choose DIN 2.4816 Threaded Fittings from Midland Alloys Inc.?
Midland Alloys Inc. is a prominent Indian producer and exporter of premium ASME SB564 forged Inconel fittings, providing customized solutions with DIN 2.4816 threaded fittings. We concentrate on precision manufacturing that meets or exceeds the requirements set for UNS N06600 forged fittings. As an ISO-certified company We provide a wide range of customization options, including end finishes, cut-to-length, irregular schedules and unique surface treatments. Our distribution network expands to the Gulf, Europe, Africa, and Southeast Asia and supports projects of any size. Every batch is verified with in-house mechanical and chemical testing, mill test certifications (MTCs), and third-party inspections on request. We ensure timely delivery, expert logistics handling, and support for both small and bulk export orders. Our goal is to build long-term partnerships through quality assurance, project accuracy and complete customer satisfaction. All ASTM B564 Inconel 600 forged fittings are clearly marked per industry norms and are supplied with full traceability and compliance documentation.
FAQs – Inconel 600 Forged Fittings
Inconel 600 forged fittings prices vary based on factors such as size, quantity, production schedule, and special specifications.
Yes, Inconel 600 threaded forged fittings are designed to function in high-pressure and high-temperature conditions, as they possess good tensile strength and resistance to corrosion.
