Midland Alloys Inc. is a leading manufacturer and supplier of Nickel Alloy 201 Tubes, offering high-purity tubing solutions with excellent resistance to heat and corrosion. Nickel 201 (UNS N02201 / 2.4068) is a low-carbon version of Nickel 201, known for its exceptional mechanical strength, thermal stability, and resistance to alkalis and certain acidic environments. Our product range includes Nickel Alloy 201 Seamless Pipes, Thin Wall Nickel 201 Tubes, 2.4068 Polished Nickel Pipes and Nickel 201 Tubes in round, square and rectangular shapes, each one for safe operation in corrosive and high-temperature conditions. Since we are a certified company according to ISO, we ensure that our products are as per international standards such as ASTM,ASME and DIN/EN. With a strong focus on precision, quality, and customization, Midland Alloys Inc. delivers dependable solutions to clients across a wide range of industries.
Benefits of Nickel Alloy 201 Tubes
Nickel Alloy 201 Tubes deliver outstanding performance in demanding conditions. Their unique chemical makeup makes them suitable for corrosive and high-temperature environments.
- High Resistance to Corrosion
Nickel Alloy 201 is resistant to corrosion in acidic, as well as alkaline conditions such as caustic soda, and acids. It is stable even in harsh chemical processing conditions.
- High Strength and Durability
The alloy has superior mechanical strength as it can withstand stress without deforming. It maintains its structure and performance even at higher temperatures.
- Weldability
Nickel 201 is soft and weldable and can be fabricated with standard processes. It does not crack or lose strength when welding or after welding, which makes it suitable for intricate assemblies.
- Cost-effective and Easy to Maintain
With long lifespan and low requirement for maintenance, Nickel 201 lowers maintenance expenses in the long run. Its stability in harsh environments adds to its value.
- Versatility
This alloy is used in a wide range of industries like chemical processing, marine and food handling. Its purity, and strength make it suitable for many demanding applications.
- High-Temperature Performance
Nickel 201 performs efficiently at temperatures up to 1200°F (649°C). It is resistant to scaling and structural degradation under high-heat conditions.
Nickel 201 Tube Specifications
Seamless Tube OD : 1/8 -12" NPS
Welded Tube OD : 6.00 mm OD up to 914.4 mm OD
EFW Tube Size : 4 to 219mm W. T.: 0.5 to 20mm
ASTM A161, ASME SB161
Seamless / Welded / ERW / Fabricated / CDW / 100% X Ray Welded
Round, Square, Rectangular, Hydraulic Etc
Single Random, Double Random & Cut Length.
Plain End, Beveled End, Threaded
SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
No. 2B - Mill finish/ Matte finish, No.8 - Mirror finish, No. 4 - Brushed finish, Bright, Annealing, Polished, Mirror
Contact us today to discuss how Nickel Alloy 201 Tubes can benefit your application. Whether you need guidance in selecting the right Tubes or have specific requirements, our team of experts is here to help you find the optimal solution.
Technical Details & Delivery Condition
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
|---|---|---|---|---|---|---|---|---|
| Nickel 201 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Nickel 201 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
Stainless Steel Tubes Grades We Offer
Difference Between Nickel Alloy 201 Tubes and Nickel Alloy 200 Tubes
Nickel Alloy 200 and Nickel Alloy 201 are both commercially pure nickel, but the main difference is in carbon content. Nickel 201 has a maximum of 0.02% carbon, whereas Nickel 200 contains a maximum of 0.15% carbon. This reduced carbon content enhances graphitization resistance and renders Nickel 201 more suitable for service at temperatures above 315°C. Although the two alloys possess comparable corrosion resistance, and mechanical properties, Nickel 201 is superior in environments with high temperatures environments and applications involving caustic alkalis. While Nickel 201 is preferred for thermal stability and control in heat-intensive processes, Nickel 200 is often selected for general corrosion-resistant applications. UNS N02201 and UNS N02200 Pipes are used for their respective applications.
Round Bar
Analytic
Cut to Length
Centering
Heating
Perforation
Inspection of Size
Pickling
Inspection of Surface
Lubricating
Cold Drawing (Cold Rolling)
Degreasing
Annealing
Straightening
Cut
Pickling / Passivating
Inspection
Analytic
Marking
Packing & Shipping
Applications of Nickel Alloy 201 Tubes
In chemical processing industries where product purity is crucial, such as in the handling of caustic soda, salt production, and food manufacturing, nickel alloy 201 tubes are widely used. They are ideal for heat exchangers, evaporators and process piping in alkali production, marine environments, and electronic parts. These tubes are also used in aerospace components, power generation systems, and reactors where temperature and corrosion control are essential. Because of their low carbon content and thermal stability, they are also applied in equipment exposed to high temperatures and reducing conditions.
Why Choose Midland Alloys Inc. for Nickel Alloy 201 Tubes
Nickel Alloy 201 Pipes and Tubes from Midland Alloys Inc. are precisely designed and constructed to meet global quality standards. We ensure prompt delivery and reliable quality, as we have an extensive range of UNS N02201 Seamless Pipe types in stock, along with custom options. Being an ISO certified company and international exporter of Nickel alloy pipes, our products exhibit consistent performance in industries and meet ASTM, ASME and DIN/EN specifications. Dependability, accurate specifications, and long-term support on every order are also our priorities.
FAQS
With a yield strength of roughly 45 MPa (6.5 ksi), the nickel 201 can tolerate moderate stress before permanently deforming. Due to this, it can be used in applications, with moderate temperatures and low pressure.
Nickel is ferromagnetic in nature, so it can be magnetized and hold magnetic properties. It is usually alloyed with iron to produce hard and durable permanent magnets.
Gold and silver that are pure do not have nickel in them. Nickel is occasionally added to white gold alloys for increased hardness, and a silvery appearance, particularly to use in jewelry.
