Super Duplex Steel UNS S32760 Forged Fittings Manufacturer & Supplier

Midland Alloys Inc. Inc is a reputable Indian manufacturer and international supplier of Super Duplex Steel Forged Fittings offering top notch goods to a range of industrial markets. Our Super Duplex Steel UNS S32760 Forged Fittings offer exceptional mechanical strength and corrosion resistance. These fittings are engineered to connect pipes or change the direction of flow in aggressive environments like marine, offshore, and chemical plants. These parts which are made of UNS S32760, also called Alloy 2507 satisfy strict international standards such as ASTM A182 and ASME SA182. With trace additions like Cu: 0.5%, the chemical composition consists of 0.030% C, 0.24–0.32% N, 24–26% Cr, 6–8% Ni and 3–5% Mo. Outstanding performance in various application is guaranteed by mechanical attributes like a maximum hardness of 310 HB, a tensile strength of 795 MPa and a proof stress of 550 MPa. We offer both S32760 forged socket weld fittings and S32760 forged threaded fittings, tailored for robust use.

Benefits of Super Duplex Steel UNS S32760 Forged Fittings

Forged stainless steel fittings that meet UNS S32760 standards offer an exceptional blend of robustness, longevity and resistance to corrosion. Because of these characteristics, they are the perfect choice for high demand systems that must function in harsh environments with high temperatures, pressures and corrosive substances.

High PREN ensures excellent resistance to pitting in chloride-rich environments
Dual-phase structure enhances both strength and corrosion resistance
Superior tensile and yield strength for high-pressure performance
Excellent weldability supports easy fabrication and on-site installation
Good impact resistance even at sub-zero temperatures
Increased fatigue strength for long-term durability under vibration
Stress corrosion cracking resistance for safe operation in harsh chemicals
Minimal maintenance needs reduce downtime and operational costs

Difference between Super Duplex Steel UNS S32760 vs. S32750 Forged Fitting

Although Super Duplex Steel UNS S32760 and UNS S32750 Forged Fitting both belong to 2507 alloy and have comparable corrosion resistance qualities, S32760 has extra elements like copper and tungsten that improves its resistance to corrosion and sulphide stress corrosion. S32760 is better suited for harsh chloride bearing environment like offshore platform and subsea pipeline because it also tends to have slightly better mechanical qualities and pitting resistance (PREN > 40) than S32750. In short, S32760 forged pipe fittings offer marginally improved strength and corrosion durability over S32750 in extreme conditions.

Specification of Super Duplex Steel UNS S32760 Forged Fittings

Types of Super Duplex Steel UNS S32760 Forged Fittings

Manufacturing Types

Threaded Forged Fittings

Designed with internal or external threads, these fittings allow quick assembly and disassembly without welding.
Socket Weld Forged Fittings

These fittings are joined by inserting the pipe into a recessed area of the fitting and welding around it, ensuring strong, leak-proof joints.
Screwed Fittings

Similar to threaded types, screwed fittings are connected using screw threads, making installation simple and cost-effective.
BSPT

Bushings help reduce the bore size in a fitting or valve connection by joining pipes of varying diameters.
NPT

End caps are used to seal a pipeline's end, shielding it from impurities and guaranteeing closed systems' safety.

Forms

Forged Elbow

Elbows, which come in 45° and 90° varieties shift the direction of flow with little pressure loss.
Forged Bushing

Bushings help reduce the bore size in a fitting or valve connection by joining pipes of varying diameters.
Forged Tee

Used to split or combine flow across three directions essential for branching pipeline.
Forged Coupling

Offer a safe connection between two pipes; threaded and socket-welded options are available.
Forged Plug

Close open pipe ends which are frequently used for isolation or testing.
Forged Cross

With four openings, cross fittings help connect four pipes used when fluid distribution needs to occur in multiple directions.

Contact Midland Alloys Inc. for Your Super Duplex Steel UNS S32760 Forged
Fittings Needs

Contact us today to discuss how Super Duplex Steel UNS S32760 Forged Fittings can benefit your application. Whether you need guidance in selecting the right pipes or have specific requirements, our team of experts is here to help you find the optimal solution.

Technical Details & Delivery Condition

Chemical Composition of Super Duplex Steel UNS S32760 Forged Fittings

Element	C	Mn	Si	P	S	Cr	Mo	Ni	N	Fe
S32760	0.05 max	1.00 max	1.00 max	0.030 max	0.010 max	24.00 – 26.00	3.00 – 4.00	6.00 – 8.00	0.20 – 0.30	57.61 min

Mechanical Properties of Super Duplex Steel UNS S32760 Forged Fittings

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Super Duplex Steel S32760	7.8 g/cm3	1350 °C (2460 °F)	Psi – 116000 , MPa – 800	Psi – 80000 , MPa – 550	15 %

Super Duplex Steel UNS S32760 Forged Fittings Equivalent Grade

Standard	Equivalent Grade
AISI / ASTM	S32760
UNS	S32760
EN / DIN	1.4501 / 1.4507
JIS	–
GB / China	–
Werkstoff / Germany	1.4501 / 1.4507
AFNOR / France	Z3CND25.11
BS / UK	–

Duplex & Super Duplex Steel Forged Fittings Grades We Offer

Duplex Steel Forged Fittings

Duplex Steel UNS S31803 Forged Fittings

Duplex Steel UNS S32205 Forged Fittings

Super Duplex Steel Forged Fittings

Super Duplex Steel UNS S32750 Forged Fittings

Super Duplex Steel UNS S32760 Forged Fittings

Socket Weld Fittings Dimensions

Threaded Fittings Dimensions

Tolerance Chart

Socket Weld Fittings Dimensions

Threaded Fittings Dimensions

Tolerance Chart

Manufacturing Process of Super Duplex Steel UNS S32760 Forged Fittings

Raw Material

Cutting

Sizing

Heat Treatment

Pickling

Beveling

Polishing

Sand Blasting

Pickling / Passivating

Inspection

Analytic

Marking

Packing & Shipping

Applications of UNS S32760 Stainless Steel Forged Fittings

In industries where corrosion resistance and structural integrity are important , SDSS S32760 forged fittings are essential. In the oil and gas sector, these fittings are used in pipeline systems, valves and pressure control modules for offshore drilling rigs and refineries. They are essential to the safe transportation of corrosive acid and alkalis via containment vessels, pumps and pipes in chemical processing facilities. Desalination facilities deploy S32760 seamless forged fittings to handle seawater and brine under high pressure. These fittings are used in ballast systems, underwater piping, and shipbuilding in the maritime sector. In power generation, they are crucial for boiler feed systems and condensers.The pulp and paper sector uses ANSI/ASME B16.11 super duplex fittings to handle hot and corrosive chemical. In food and pharma, they help ensure hygiene and corrosion-free operation. Because of their high strength-to-weight ratio their mechanical integrity is also useful in hydraulic systems and aerospace fuel lines.

Offshore Industry

Nuclear Industries

Refineries

Ship Building

Aerospace

Pharmaceutical

Why Choose Midland Alloys Inc. for ASTM A182 S32760 Forged Fittings

We manufacture and export high-quality Super Duplex Steel UNS S32760 Forged Fittings with a strong commitment to precision manufacturing. Our procedures are ISO 9001:2015 certified and we closely follow DIN 1.4410, ASTM A182 and ASME SA182 standards. S32760 forged threaded fittings, welded super duplex S32760 fittings and cut-to-length options are among the many sizes, schedules and end connections that our fittings come in. We provide quick delivery and customized solutions to customers in Europe, Africa, the Gulf and Southeast Asia. Our in-house testing labs, mill test certifications (MTCs), and third-party inspection capabilities ensure unmatched product reliability. We prioritize quality control and long term collaborations while supporting project-based needs with both small batch and bulk dispatches. Every fitting is labeled in accordance with ASTM/ASME standards and comes with Mill Test Certificates attesting to its mechanical and chemical compliance. Our products are securely packed and labelled for international export.

FAQs – Super Duplex Steel UNS S32760 Forged Fittings

What is the pressure rating of Super Duplex S32760 forged pipe fittings?

Although the pressure rating varies by size and type it usually complies with ASME B16.11’s Class 3000, 6000 or 9000 standards.

Are SDSS S32760 forged fittings suitable for sour gas service?

Yes, their enhanced resistance to sulphide stress corrosion cracking makes them ideal for sour service applications.

What’s the difference between socket weld and threaded S32760 forged fittings?

Socket weld fittings provide stronger, leak-proof joints and are better for higher-pressure systems. Threaded fittings are easier to assemble/disassemble in low-pressure or temporary setups.

Can S32760 forged fittings be used in cryogenic applications?

Yes, they maintain good impact strength even at low temperatures, making them suitable for cryogenic environments.

What is the availability of S32760 forged fittings in India?

As a leading UNS S32760 forged fittings manufacturer in India, Midland Alloys Inc. maintains ready stock and offers competitive S32760 forged fittings price per kg.

How do you ensure quality for DIN 1.4410 forged fittings?

We follow strict QA/QC protocols, including chemical analysis, mechanical testing, PMI, and third-party inspection, ensuring compliance with international standards.

Nominal Size		Socket Bore Dia	Bore Dia of Fittings			Socket Wall Thickness						Body Wall			Depth of Socket	Center to Bottom of Socket
D N	NPS	B	D			C						Gmin			J min	A
			3000	6000	9000	3000		6000		9000		3000	6000	9000		90° Elbow Tee Cross			45° Elbow
			3000	6000	9000	ave	min	ave	min	ave	min	3000	6000	9000		3000	6000	9000	3000	6000	9000
6	1/8	10.9	6.1	3.2		3.18	3.18	3.96	3.43			2.41	3.15		9.5	11.0	11.0		8	8
8	1/4	14.3	8.5	5.6		3.78	3.30	4.60	4.01			3.02	3.68		9.5	11.0	13.5		8	8
10	3/8	17.7	11.8	8.4		4.01	3.50	5.03	4.37			3.20	4.01		9.5	13.5	15.5		8.0	11.0
15	1/2	21.9	15.0	11	5.6	4.67	4.09	5.97	5.18	9.53	8.18	3.73	4.78	7.47	9.5	15.5	19.0	25.5	11	12.5	15.5
20	3/4	27.3	20.2	14.8	10.3	4.90	4.27	6.96	6.04	9.78	8.56	3.91	5.56	7.82	12.5	19.0	22.5	28.5	13	14	19
25	1	34	25.9	19.9	14.4	5.69	4.98	7.92	6.93	11.38	9.96	4.55	6.35	9.09	12.5	22.5	27.0	32.0	14.0	17.5	20.5
32	1-1/4	42.8	34.3	28.7	22.0	6.07	5.28	7.92	6.93	12.14	10.62	4.85	6.35	9.70	12.5	27.0	32.0	35.0	17.5	20.5	22.5
40	1-1/2	48.9	40.1	33.2	27.2	6.35	5.54	8.92	7.8	12.70	11.12	5.08	7.14	10.15	12.5	32.0	38.0	38.0	20.5	25.5	25.5
50	2	61.2	51.7	42.1	37.4	6.93	6.04	10.92	9.5	13.84	12.12	5.54	8.74	11.07	16.0	38.0	41.0	54.0	25.5	28.5	28.5
65	2-1/2	73.9	61.2			8.76	7.62					7.01			16.0	41.0			28.5
80	3	89.9	76.4			9.52	8.30					7.62			16.0	57.0			32.0
100	4	115.5	100.7			10.69	9.35					8.56			19.0	66.5			41.0

Nominal Size		Center-to-End						Outside Diameter of Band			Wall Thickness			Length of Thread
DN	NPS	A						H			G min			min	mim
		90° Elbows, Tees, Crosses			45° Elbows			H			G min
		2000	3000	6000	2000	3000	6000	2000	3000	6000	2000	3000	6000
6 8 10	1/8 1/4 3/8	21 21 25	21 25 28	25 28 33	17 17 19	17 19 22	19 22 25	22 22 25	22 25 33	25 33 38	3.18 3.18 3.18	3.18 3.30 3.51	6.35 6.60 6.98	6.4 8.1 9.1	6.7 10.2 10.4
15 20 25	1/2 3/4 1	28 33 38	33 38 44	38 44 51	22 25 28	25 28 33	28 33 35	33 38 46	38 46 56	46 56 62	3.18 3.18 3.68	4.09 4.32 4.98	8.15 8.53 9.93	10.9 12.7 14.7	13.6 13.9 17.3
32 40 50	1-1/4 1-1/2 2	44 51 60	51 60 64	60 64 83	33 35 43	35 43 44	43 44 52	56 62 75	62 75 84	84 102	3.89 4.01 4.27	5.28 5.56 7.14	10.59 11.07 12.09	17.0 17.8 19.0	18.0 18.4 19.2
65 80 100	2-1/2 3 4	76 86 106	83 95 114	95 106 114	52 64 79	52 64 79	64 79 79	92 109 146	102 121 152	121 146 152	5.61 5.99 6.55	7.65 8.84 11.18	15.29 16.64 18.67	23.6 25.9 27.7	28.9 30.5 33.0

Minimal Diam.		Outer Dia. For Bevel End	Inner Dia. For End	Elbow		Tee		Reducer	Cap	180° Elbow
DN	NPS			A	B	C	M	H	E	O	K	Roughness
500-600	20-24	+6.4/-4.8	4.8	3.2	3.2	3.2	3.2	4.8	9.6	–	–	–
650-750	26-30
				4.8	4.8	4.8	4.8
800-1200	32-48
1250-1500	50-60	+9.6/-6.4	6.4	9.6	9.6	9.6	9.6	9.6	–
1550-1750	62-70	+12.7/-9.6	9.6	12.7	12.7	–
1800-2000	72-80	+16/-12	12	16	16
15-65	1/2-2 1/2	+1.6/-0.8	0.8	1.6	1.6	1.6	1.6	1.6	3.2	6.4	6.4	0.8
80-100	3-4	1.6	1.6						6.4
125-200	5-8	+2.4/-1.6
250-450	10-18	+4/-3.2	3.2	2.4	2.4	2.4	2.4	2.4		9.6
